Get a custom filling solution designed around your product, container, and target throughput.
Capping Machines
The QG-1 is the handheld capper: a pneumatic or electric pistol that tightens 10-50 mm screw and ROPP closures at a set torque. It is the cheapest entry to consistent capping for artisan, lab, and low-volume runs.
Working Speed
15 – 30 BPM (manual)
Applicable Cap Type
screw cap, ROPP, 10 – 50 mm
Torque Control
Mechanical / magnetic clutch
公模代号 / Public Mold Code: QG-1
The QG-1 is the handheld capper: a pneumatic or electric pistol that tightens 10-50 mm screw and ROPP closures at a set torque. It is the cheapest entry to consistent capping for artisan, lab, and low-volume runs.
Primary Metric
15 – 30 BPM (manual)
Control Stack
Manual (no PLC) + Airtac
Contact Material
Rubber chuck
Electrical
220V / cordless optional
Project CTA
Share your container size, target speed, and product behavior. We will match the right equipment configuration and send a technical response.
No Price Listed
This catalog is quote-driven. Final pricing depends on container format, filling range, control options, and downstream integration scope.
| Frame Material | Alloy / ABS |
|---|---|
| Contact Part Material | Rubber chuck |
| PLC Brand | Manual (no PLC) |
| Pneumatic Brand | Airtac |
| Electrical Brand | 220V / cordless optional |
| Power Supply | 110 / 220V or pneumatic |
| Air Pressure | 0.4 - 0.6 MPa |
| Power Consumption | 0.2 |
| Working Speed | 15 – 30 BPM (manual) |
| Applicable Cap Type | screw cap, ROPP, 10 – 50 mm |
| Torque Control | Mechanical / magnetic clutch |
| Applicable Container | bottle, jar |
| Dimensions (L x W x H) | 300 x 100 x 200 mm |
| Weight | 2 kg |
Key Features
Pistol-grip pneumatic or electric capper for low-volume and lab use
Adjustable clutch sets a consistent torque on 10-50 mm closures
Swappable chuck jaws cover screw and ROPP caps
Light enough to hand to an operator at any bench
Industrial automation platform for repeatable cycle control; brand selectable per project.
Clean actuation and serviceable pneumatic components; brand selectable per project.
Suitable for food, cosmetic, and chemical product contact areas.
Documentation and safety configuration prepared for export projects.
Application limits
Not applicable - dry closure.
